Brief Introduce 简要介绍
Innovative blistering machine practical and compact used to make high-quality blisters from pre-cut plastic and aluminium sheets. All operations needed for blister packaging are carried out simply and quickly on the same machine, by changing and replacing the format-related parts and with no need to resort to wrenches or specialised personnel Personalised projects can be developed based on the customer's actual requests, and made-to-measure moulds can be made in terms of dimension, configuration and quantity of blisters. Electric and electronic management is ensured by high-precision instruments installed on the machine that make it possible to produce high-quality blisters.
创新的泡罩机实用和紧凑,可以从预切塑料和铝板用于制造高质量的泡罩。泡罩包装所需的所有操作进行简单而迅速,在同一台机器上,通过改变和替换插件部分和不需要诉诸扳手或专业人员就可以开发个性化的项目。根据客户的实际要求,和定制的模具可在尺寸方面,配置和需要数量的泡罩。电气和电子管理是确保高精密仪器安装在机器上,使它有可能产生高质量的泡罩。
MAIN CHARACTERISTICS 主要特点
-
Semi-automatic blistering machine
半自动泡罩包装机
-
Machine with compact dimensions for or on bench with pivoting wheels
机器结构紧凑,可用于桌面放置
-
Management and control of processing times through high-precision timers
高精度计时器管理和控制处理时间
-
Management and control of the temperatures through high-precision thermoregulators
高精度加热器管理和控制温度
-
Built-in safety systems
内置安全系统
-
Electronic piece counter
电子计数器
-
Blisters made of PVC-ALU
可做铝塑泡罩
-
Blisters made of ALU-ALU
可做铝铝泡罩
-
Plastic material forming area 212x132mm
塑料材料成型区域212*132mm
-
Maximum height of PvC blister pockets 18 mm
塑料泡罩最大深度18mm
-
Maximum height of ALU-ALU blister pockets 10.5 mm
铝铝泡罩最大深度10.5mm
-
The machine can be positioned on a bench equipped with pivoting wheels for easy handling inside the department
机器可以被放置在带轮子桌面上,方便在部门间移动。
PRODUCTON 产量
-
Daily production (7 hours) of blisters made of PVC-ALU up to approx 3,000 units
铝塑泡罩日常产量(7小时)最高可达3000片
-
4 blisters per stroke, maximum format 100x60 mm
每次4版,最大模具面积100*60mm
-
Daily production (7 hours)of blisters made of ALU-ALU up to approx 1 300units
铝铝泡罩日常产量(7小时)最高可达1300片
-
1 blister per stroke, maximum format 160x95 mm (or smaller size)
铝铝泡罩每次一板,最大模具面积160*95mm(或更小尺寸)
